In modern electrical engineering, switchgear is the core infrastructure that ensures safe distribution and control of electrical power

Whether applied in industrial plants, infrastructure projects, or EPC developments, switchgear must operate reliably under both normal and fault conditions.

To achieve this, engineers rely on a set of defined technical parameters that determine the operational limits and performance of the system.
At Shanghai Risentric (www.risentric.com), switchgear systems are engineered according to international IEC standards to ensure reliability across LV, MV, and HV applications.

Electrical parameters overview

Rated Voltage (Ur)
Rated voltage defines the maximum operating system voltage.
• LV systems: up to 1kV
• MV systems: 1kV – 36kV
• HV systems: above 36kV

It directly influences insulation design, clearance distance, and system safety margins.

Rated Current (In)

Rated current is the continuous current that switchgear can carry without exceeding temperature rise limits.

Key influencing factors:

  • Busbar material (copper/aluminum)
  • Ambient temperature
  • Enclosure ventilation design

Proper selection ensures stable thermal performance in long-term operation.

Short-Circuit Withstand Current (Icw / Icc)

  • One of the most critical safety parameters.
  • Icw: short-time withstand current (1s / 3s)
  • Icc: peak short-circuit current

This parameter ensures the switchgear can survive fault conditions without mechanical deformation or thermal failure.

Insulation Level

Defined by:

  • Power frequency withstand voltage
  • Lightning impulse withstand voltage

It ensures protection against transient overvoltage events such as lightning strikes or switching surges.

Protection Degree (IP Rating)

Ingress Protection defines environmental resistance:

  • IP54: standard indoor industrial use
  • IP65: dust-tight & water-resistant outdoor applications

Higher IP ratings are essential for harsh EPC environments.

Mechanical and functional parameters

Breaking Capacity

The ability of circuit breakers to interrupt fault current safely and effectively.

Making Capacity

Ability to close onto a fault without damage.

Form of Separation (Form 1–4)

Defines internal compartmentalization level, improving:

  • Operator safety
  • Maintenance isolation
  • Arc fault containment

Temperature Rise Limits

Ensures equipment operates within safe thermal thresholds under full load conditions.

Engineering importance in EPC projects

In EPC and industrial applications, incorrect switchgear parameter selection can lead to:

  • Equipment failure under fault conditions
  • System instability or shutdown
  • Safety risks for personnel
  • Non-compliance with IEC standards

Therefore, precise engineering coordination between transformers, protection relays, and switchgear systems is essential.

Industry Applications

Switchgear parameters are critical in:

  • LV/MV power distribution systems
  • Substations and compact substations
  • MCC and ATS systems
  • Renewable energy integration (solar + BESS)
  • Industrial automation and PLC-controlled systems

Modern EPC projects require highly customised solutions with integrated protection and control logic.

Switchgear parameters form the technical foundation of electrical power system design. Each parameter—from voltage rating to short-circuit withstand capability—ensures safe, reliable, and efficient operation of modern power networks.

As global energy systems evolve toward greater automation and renewable integration, precise switchgear engineering remains essential for ensuring operational safety and system resilience.

By Kobe Chen | Shanghai Risentric Electric Co., Ltd.
