Integrated offers an innovative, world-class suite of complete solutions for engineering and scientific designs involving multiple disciplines – creating simulation software programs that analyze a full spectrum of physical problems. We provide a complete line of fully integrated 2D and 3D simulation software and we are the experts in electromagnetics and particle trajectory design analysis.
Integrated Engineering software is the industry leader in Boundary Element Method (BEM) CAE software. Today no one else in the market offers such a variety of field solvers within the same software packages (Boundary Element Method, Finite Element Method and Finite Difference Time Domain)
Since our inception in 1984, we have focused on research and development using the latest tools and techniques. New simulation capabilities and cutting-edge technology features are constantly being incorporated into the programs.
At integrated we are proud of our customer service team and offer the highest level of service in the industry. Starting with the very first contact, our professional team is available to fully discuss design needs.
With 37+ years of experience, unrivaled research and development team, superlative sales professionals and an outstanding technical support team, we can quickly and effectively address the design needs of customers. All departments work as a team to provide our customers with an exceptional business experience.
Product Spotlight
Electro the 2D/RS electric field solver from Integrated Engineering Software has set the standard for electric field design software. It combines the advantage of both the BEM and FEM field solvers and provides fast and accurate calculations for electric field strength, force, torque, transmission line parameters and capacitance. It is the only clear choice for applications requiring large open region analysis and exact modeling of boundaries. It is an easy-to-use, powerful electrostatic field analysis tool right to your desktop. The most challenging analysis problem occurs when both nonlinearities and open regions are present. Here again Integrated takes the lead providing HYBRID field solutions using BEM and FEM simultaneously to exploit the strengths of both methods.
Coulomb is a powerful 3D electric design and analysis software featuring our innovative Boundary Element Method (BEM) technology, well suited for applications where the design requires a large open field analysis and exact modeling of boundaries. The Finite Element Method (FEM) is also available in the same package, allowing designers to select the most suitable solver according to their application, and verify the results independently within just one program. It combines exceptional ease of use, speed and accuracy; all in one fully integrated software package. It provides outstanding visualization features for detailed analysis of electrical and electronic systems. Within one package and without extra costs, Coulomb combines capabilities such as corona ring, partial discharge, electric field stress, lightning, transient events, maximum field strength and dielectric breakdown, among others.
Outstanding features of INTEGRATED’s Electro and Coulomb
- Intuitive and structured interface which maximizes productivity for experts and beginners alike
- Static, phasor and transient analysis modes
- Ability to assign constant or non-uniform charge distributions to surfaces
- Electrostatic force and torque calculations on surfaces and volumes
- Conductance and capacitance calculations
- A variety of display forms for plotting scalar and vector field quantities including graphs, contour plots, arrow plots, profile plots, streamline plots and vector loci plot
- Data exportable to formatted files for integration with spreadsheets and other software packages
- Powerful parametric feature which allows the definition of variable parameters to be stepped through for the analysis of multiple “what-if” scenarios, facilitating design optimization
- Self-adaptative meshing or optional user refinement
- CAD healing utilities for automatic correction of drafting errors
- Large library of dielectric and conductive materials to which additional materials can be easily added
Amperes is INTEGRATED’s powerful 3D magnetic field solver offering superior design capabilities in one fully integrated package. It greatly expands your design potential and allows you to simulate and optimize electromagnetic components and systems before the manufacturing stage. Avoid building multiple prototypes. Lower your development costs and times
Faraday a 3D time-harmonic Eddy Current field solver from INTEGRATED gives you the advantage you need to meet this challenge head-on. Using our innovative Boundary Element Method (BEM) and Finite Element Method (FEM) technologies, Faraday is the only clear choice for applications requiring large open region analysis, exact modeling of boundaries, and problems that deal with small skin depths.
Please check out our product portfolio here for more products
INTEGRATED’s competitive advantages:
- Combination of BEM, FEM, and FDTD solvers for multidisciplinary analysis
- Extremely intuitive and very easy-to-use interface
- Induced charge and corona calculations
- Accommodation of very large size differences in the same problem
- Continually updated extensive Model Library
- Program your own applications with API using Visual Basic, Python and Excel.
Services
Ask for a Free Evaluation of our software or book a Free Live Demo, today.
